How to Set Up, Operate, and Store the Active 2.0 Pressure Washer

How to Set Up, Operate, and Store the Active 2.0 Pressure Washer

In this post, we’ll walk you through the setup, operation, and proper storage of the Active 2.0 Pressure Washer. Whether you’re new to pressure washers or just want to refresh your knowledge, this guide covers every detail to ensure you get the best performance from your unit.

1. Setting Up the Active 2.0 Pressure Washer

To begin setting up the unit, we will first connect the high-pressure hose to both the unit and the spray gun:

  • Step 1: Locate the pump outlet on your unit (anodized male threaded connection) and connect the hose by turning it clockwise until hand-tight.
  • Step 2: Locate the gun inlet and connect the other end of the hose by turning it until hand-tight.
  • Step 3: Connect your garden hose to the water inlet of the unit (female brass connector) and ensure it's tight.
  • Step 4: Turn on the water supply. Important: Always ensure the water is on before starting the unit to avoid damaging the pump.

2. Connecting the Spray Wand and Tips

Next, we’ll set up the spray wand and the desired spray tip:

  • Step 5: Holding the gun in your left hand, connect the threaded end of the metal wand to the gun and turn counterclockwise.
  • Step 6: To attach the spray tip, slide back the collar of the wand, insert the tip, and release the collar to lock it in place.

3. Powering On the Unit

Before powering on your pressure washer, ensure it’s properly connected to a power source:

  • Step 7: Ensure the unit’s power switch is set to the OFF position.
  • Step 8: Plug the unit into a power outlet with its built-in Ground Fault Circuit Interrupter (GFCI). Test and reset the GFCI before use.
  • Step 9: Purge the unit by releasing any trapped air. Hold the trigger until a steady stream of water flows out.
  • Step 10: Finally, switch the unit ON. The Active 2.0’s Total Stop System (TSS) will ensure the motor shuts off when the trigger is not engaged.

4. Changing Spray Tips and Using the Foam Blaster

If you want to change spray tips or use the foam cannon during a cleaning session:

  • Step 11: Engage the safety lock, remove the current spray tip, and insert the desired one.
  • Step 12: For the foam blaster, detach the wand, fill the bottle with detergent, and attach the foam blaster to the gun.

When using the foam cannon, it’s best to apply detergent to a dry surface and allow it to soak for a few minutes before rinsing. After use, clean the bottle by filling it with water and spraying for a minute to remove any leftover soap.

5. Proper Shutdown

To extend the life of your pressure washer, follow these steps for a proper shutdown:

  • Step 13: Turn off the water supply and disconnect the garden hose.
  • Step 14: Pull the trigger to release any remaining water pressure.
  • Step 15: Set the unit’s power switch to OFF and unplug it.
  • Step 16: Engage the gun’s safety lock and disconnect the hoses for storage.

Winterizing the Active 2.0 Pressure Washer

If you live in a cold climate, it’s important to winterize your pressure washer to prevent damage from freezing:

  • Option 1: Use a pressure washer antifreeze canister. Attach it to the water inlet, depress the button until antifreeze exits the hose, then disconnect.
  • Option 2: Disconnect all water connections and run the unit for a few seconds to expel remaining water. Store the unit and accessories in a space above freezing temperatures.

Be sure not to store the unit too close to heat sources like furnaces, which could dry out pump seals.

Conclusion

That wraps up this guide to setting up, operating, and storing your Active 2.0 Pressure Washer. Proper care and maintenance will ensure your unit continues to perform at its best for years to come. If you have any further questions or need assistance, feel free to contact us at support@activeproducts.com.

Thanks for reading, and we hope to see you in our next guide!
